Armattan Oomph Titan Edition 2306 2450 KV Motor - CW or CCW
Armattan Oomph Titan Edition 2306 2450 KV Motor - CW or CCW
Couldn't load pickup availability
|
|
|
Motor Specifications |
|
|
Stator Diameter |
23mm |
|
Stator Height |
6mm |
|
KV (rpm/Volt) |
2450 |
|
Weight |
~30.5 grams (trimmed wires) |
|
Wire Length |
19cm (untrimmed) |
|
Recommended Props |
5 or 6 inch |
|
LiPo Compatibility |
3-4S |
|
Prop Mount Height |
5mm |
|
Prop Mount Diameter |
5mm |
|
Interior Threading |
CW or CCW |
|
Magnets |
N54H magnets |
|
Stator Laminations |
Laminated for smoothness |
|
Winding |
Single Wire |
|
Bearing |
684 NSK 4x9x4 |
Armattan
Introducing the latest addition to the Armattan Oomph line of motors. Titans!
Much like its smaller brother, the Oomph Velvet, this 2306 version is also designed for smoothness, but with a fair bit more torque. We use the same prong as we do on all our Oomph motors, except we reduced it to only 3 of them and we also also shaved off the motor base to save even more weight.
Efficiency, lightweight and low amp draw and low cost without compromises is what we wanted in this motor. While we think it is better suited for freestyle, many racers will appreciate the low end torque of this new Oomph motor.
